Model:602A 602B
|
|
|
|
|
| Smooth and labor-saving | Premium Material | Suitable for All Kinds of Ground | High Bearing Capacity | Fast Delivery |
1.5 inches diameter black nylon twin wheels with specialized u-bracket mount for pressboard furniture. U-shaped mount envelopes pressboard from 5/8 inches to 3/4 inches thick and is secured with a screw to support weight without damaging fragile pressboard. This caster series has a die cast elextrophoretic coating steel body for durablility and boasts mounting options that include top plates(504), threaded stems(503), grip ring stems(505), grip neck stems(508) and U-bracket(602). A great choice under pressboard furniture with specialized u-bracket mount. There is a pedal brake option and has three available color finishes for body: black, grey and white.
| Caster Code | Description | Unit | Wheel Diameter | U-Bracket Inner Width | Mounting Height |
Wheel Material |
Load Capacity | Wheel Width | Application | Color | Package |
| 602A | U-Clamp Top Rotatable Universal Swivel Brake Caster | Piece |
Φ40mm (1 1/2") |
16mm/18mm/19mm (Max. 3/4" board) |
2 3/16" (55mm) |
Nylon+ Polypropylene (PA:Black)+ (PP:Grey/White) |
55LBS (25KG) |
40mm | U-Shaped Clamp Caster Wheel, 40mm diameter, with locking option, safety for baby crib legs installation. |
Black/ Grey White |
200pc/ctn |
| 602B | U Shaped Top Rotatable Universal Swivel Caster W/O Brake | Piece |
Φ40mm (1 1/2") |
16mm/18mm/19mm (Max. 3/4" board) |
2 3/16" (55mm) |
Nylon+ Polypropylene (PA:Black)+ (PP:Grey/White) |
55LBS (25KG) |
40mm | Caster Wheel 1.5" Inch with Brake Special Design U-Bracket Caster. |
Black/ Grey White |
200pc/ctn |
